| Standard Colour： | Light Grey |
| Customized Colours (Subject to Minimum Order Quantity)： | Olive Green, Brown, Clay, Tan & Other RAL colours |
| UV Protection： | Smallboss Vinyl Sheet Piles are manufactured from highly weatherable, UV-stabilised and rigid PVC |
| L/mm | Ll/mm | L2/mm | L3/mm | H/mm | ∠A/° | T/mm |
| 606 | 108 | 390 | 108 | 222-236 | 98 | 5-12 |
| Material | pvc |
| Section Width | 718 mm |
| Section depth | 180 mm |
| Length | Customization |
| Thickness | mm |
| Package | Customization |
| Color | Grey/customization |
| Weight | 16.5士1 kg/m |
| Moment of inertia | 7740 cm4/m |
| Section modulus | 792 cm3/m |
| Ultimate moment | 33.3 kNm/m |
| Tensile Strength | 45.52 Mpa |
| Flexural Strength | 68.87Mpa |
| Modulus of Elasticity | 2980 Mpa |
| Lzod impact strength | ≥60J/m |
| Simply supported beam notched impact strength |
≥6KJ/m’ |
| Vicat Softening Temp | 80℃ |
| Project | Unit | Numerical value | Test method |
| Density | (g/cm²) | 1.22-1.5 | GB/T 1033.1 |
| Tensile Strength | (Mpa) | 43-45 | GB/T 1040.2 |
| Bending strength | (Mpa) | 66-75 | GB/T 9341 |
| Impact strength | (KJ/cm²) | 2.2-6 | GB/T 1043.1 |
| Hardness | (Shaw D) | ≥79 | GB/T 2411 |
Small boss vinyl sheet pile can be used to protect and regulate rivers,ditches or channels.Thanks to their structure,the vinyl sheet pilesystem is easy to adapt to the natural curvature of the terrain,andthe construction is easier to adjust the shape of the whole sheet pilesystem according to the topography.
